More ways to connect your USB devices

The Manhattan 4-Port USB 3.2 Gen 1 Hub turns one of your device's SuperSpeed (or earlier) USB ports into two USB-A and two USB-C ports so you can easily connect a keyboard, mouse, thumb drive, smartphone, tablet or other compatible device. The hub's SuperSpeed ports are backward compatible so nearly any device connects the way it's supposed to. Devices that fit the SuperSpeed spec can reach transfer speeds up to 5 Gbps for external storage, printing and more. Plus, you can charge your phone or tablet since the hub supplies up to 5 V / 1 A of power to connected devices.

Connectivity you can take with you

This hub's durable case, compact size and bus power mean greater portability for you when you have to leave. Simply unplug the hub from your upstream device, disconnect your peripherals and put the devices you need into your laptop bag. Its Plug-and-Play installation and hot-swap ability helps you get set up to work — or play— in no time.

• Adds two USB-C and two USB-A SuperSpeed ports to connect a keyboard, mouse, flash drive, smartphone, tablet and more to your USB computer
• Supports SuperSpeed data transmission up to 5 Gbps
• Bus powered – no external power supply needed
• Includes an LED power indicator
• Plug-and-Play installation; hot swappable
• Windows and Mac compatible
• Three-year warranty

Standards and Certifications

• USB 3.2 Gen 1 (USB 3.0)

• FCC

• CE

• RoHS2

• WEEE

  General

• Data transfer speeds: 5 Gbps

• One USB-A male

• Two USB-A female

• Two USB-C female

• Up to 1 A total power output

• Bus powered

  Connections

• One USB-A, 4-pin, male

• Two USB-A, 4-pin, female

• Two USB-C, 24-pin, female

  Physical

• 24-AWG cable gauge

• Cable Length (including connector): 13.5 cm (5.31 in.)

• Withstanding voltage: 300 VDC

• Insulation resistance: 10 MΩ

• Conductive resistance: 5 Ω

• Housing: ABS plastic

• Dimensions: 90 x 45 x 15 mm (3.54 x 1.77 x 0.6 in.)

• Weight: 39 g (1.1 oz.)

• Shielded

  Operating Environment

• Operation Temperature: 0 – 40°C (32 – 104°F)

• Storage Temperature: -20 – 60°C (-4 – 140°F)

• Humidity (noncondensing): 5 – 90%

  System Requirements

• Windows XP/Vista/7/8.1/10 or Linux or Mac 9.x/10.x or above

  Package Contents

• 4-Port USB 3.2 Gen 1 Hub

• Quick Instruction Guide
