Easily connect a Mini DisplayPort source with an HDMI, DVI or VGA display

The Manhattan 3-in-1 4K Mini DisplayPort Adapter establishes a fast, simple and convenient link between a Mini DisplayPort source and a 4K HDMI or 1080p DVI and VGA displays. The adapter is easy and quick to install and requires no complicated configuration or setup. It offers an active connection for VGA and a passive connection for HDMI and DVI as well as a compact and integrated solution that eliminates unnecessary cables, tangles and clutter to keep installations and workspaces neat and orderly.

• 3-in-1 adapter converts a Mini DisplayPort signal to a 4K@30Hz HDMI or 1080p@60Hz DVI or VGA signal (no simultaneous output)
• Delivers a high-quality digital video signal — ideal for using a Mini DP source with an HDMI, DVI or VGA display
• Supports Deep Color, high-bandwidth 3 Gbps applications and resolutions at 1080p@60Hz (up to 1920 x 1200) for VGA and DVI or 4K@30Hz (3840 × 2160) for HDMI
• Allows monitor, TV or display to be configured in Extended or Mirrored modes
• HDMI configuration supports Ultra-High-Definition (UHD) video resolution up to 4K@30Hz (3840 x 2160p) and uncompressed digital 5.1 audio
• DVI configuration supports high definition video resolution up to 1080p@60Hz (1920 x 1080p); DVI does not support audio
• VGA configuration supports high-definition video resolution up to 1080p@60Hz (1920 x 1080p); VGA does not support audio
• Compatible with DVI-I and DVI-D interfaces
• Integrated design simplifies connections and eliminates cable tangles and clutter
• Three-year warranty

Standards and Certifications

• UL 20276

• DisplayPort v1.2

• FCC

• CE

  Connections

• Mini DisplayPort 20-pin male

• HDMI 19-pin female, passive

• DVI-I 24+5-pin female, passive

• VGA/HD15 15-pin female, active

• Nickel-plated contacts

• Molded PVC and ABS Shell

  General

• 8-bit and 10-bit Deep Color support

• 3 Gbps bandwidth

• Maximum single link resolution
  3840 x 2160 (4K@30Hz) for HDMI
  1920 x 1200 (1080p@60Hz) for DVI and VGA

• One-lane, one-direction, four-line connection support

• Active

  Video Resolutions

• VGA: 640x480, 800x600, 1024x768, 1920x1200

• DTV/HDTV/UHDTV: 480i/480p/576i/576p/720p/1080i/1080p/4K@30Hz

  Physical

• Cable length: 25 cm (10 in.)

• Housing: 7.5 x 4 x 1.8 cm (2.95 x 1.8 x 0.7 in.)

• Weight: 48 g (1.7 oz.)

• Housing: plastic

  Operating Environment

• Operation Temperature: 0 – 40°C (32 – 104°F)

• Storage Temperature: -20 – 60°C (-4 – 140°F)

• Humidity (noncondensing): 0 – 80%

  System Requirements

• Windows XP/Vista/7/8.1/10, Linux or Mac 9.x/10.x or above

  Package Contents

• 3-in-1 4K Mini DisplayPort Adapter

• Quick Instruction Guide

• Additional SKUs

• Amazon ASIN: B07GJWTY1D
• EAN: 0766623207362
• UPC: 766623207362



• Physical Specifications

• Product net weight: 0.05 kg
• Product gross weight: 0.1 kg
• Dimensions: 65 (L) x 65 (W) x 15 (H) [mm]
• Packaging: Blister
